The freezer fan motor is an important component of your GE freezer. It helps to circulate cold air throughout the freezer and keep your food frozen. If the freezer fan motor fails, it can cause your freezer to stop cooling properly, make loud or unusual noises, or frost up excessively. In this case, you may need to replace the freezer fan motor with a new one.
To replace the GE freezer fan motor, you need to unplug your freezer, remove the freezer door and drawers, remove the back panel inside the freezer, disconnect the wires and harnesses from the old motor, pull out the old motor and fan blade, install the new motor and fan blade, reconnect the wires and harnesses, reinstall the back panel, door, and drawers, and plug in your freezer.
The process may vary slightly depending on your freezer model and the type of fan motor you have.
How To Replace GE Freezer Fan Motor: Step by Step Guide
Here are the steps to follow to replace the GE freezer fan motor:
- Step 1: Gather your tools. You will need a Phillips screwdriver, a flathead screwdriver, a pair of needle-nose pliers, a multimeter (optional), and a new freezer fan motor that matches your freezer model. You can find the model number of your freezer on a label inside the refrigerator compartment or on the back of the appliance. You can order a new fan motor online or from a local appliance parts store.
- Step 2: Disconnect your freezer from the power source. To avoid electric shock or injury, you need to unplug your freezer from the wall outlet or turn off the circuit breaker that controls it.
- Step 3: Empty your freezer. To access the fan motor, you need to remove all the food and items from your freezer. You can store them in a cooler or another freezer while you work on your appliance.
- Step 4: Remove the freezer door and drawers. To remove the door, you need to unthread it from its mounting rails by lifting it up and out. To remove the drawers, you need to slide them out and lift them off their tracks. Set them aside in a safe place.
- Step 5: Remove the back panel inside the freezer. To remove the back panel, you need to unthread several screws that hold it in place. You may also need to pry off some clips or tabs with a flathead screwdriver. Be careful not to damage any wires or components behind the panel. Once the panel is loose, pull it out and set it aside.
- Step 6: Uninstall the old motor. The fan motor is located behind the back panel in a metal housing. To uninstall it, you need to disconnect the wires and harnesses that connect it to the power supply and other components. You may need to use needle-nose pliers to release some connectors or clips. You can also use a multimeter to test the motor for continuity and resistance before removing it. Once all the wires and harnesses are disconnected, pull the motor housing out of the freezer. Unthread the screws that hold the motor in place and remove them. Doing this will separate it from the fan blade.
- Step 7: Install the new motor. To install the new motor, you need to insert it into the metal housing and secure it with screws. Then, attach the fan blade to the motor shaft and make sure it spins freely. Next, slide the motor housing back into its slot in the freezer and reconnect all the wires and harnesses that you disconnected earlier. Make sure they are properly aligned and secured.
- Step 8: Reinstall the back panel inside the freezer. To reinstall the back panel, you need to align it with its holes and clips on the freezer wall and push it into place. Then, thread all the screws that you removed earlier and tighten them firmly.
- Step 9: Reattach the freezer door and drawers. To reattach the door, you need to align it with its mounting rails and slide it down until it locks into place. To reattach the drawers, you need to align them with their tracks and slide them in until they snap into place.
- Step 10: Plug in your freezer and test it. To plug in your freezer, you need to reconnect it to the wall outlet or turn on the circuit breaker that controls it. Then, check if your freezer is cooling properly and if there are any unusual noises coming from it.
We hope this post has helped you learn how to replace GE freezer fan motor with ease. If you have any questions or comments, feel free to leave them below.
