Whirlpool Refrigerator Freezer Fan: How Much It Costs And How To Replace It

If you have a Whirlpool refrigerator, you may be wondering what the freezer fan does and how much it costs to replace it. The freezer fan, also known as the evaporator fan, is a vital component that circulates cold air from the freezer to the refrigerator and helps maintain the optimal temperature for food preservation. The average cost of a Whirlpool refrigerator freezer fan is around $20 to $60, depending on the model and the part number. The replacement process is not very difficult, but it requires some basic tools and skills. In this post, we will show you how to replace the freezer fan on your Whirlpool refrigerator and save some money on repair fees.

What are the signs of a faulty freezer fan?

The freezer fan can fail due to various reasons, such as wear and tear, frost buildup, or electrical issues. Some of the common signs of a faulty freezer fan are:

• The refrigerator is warm or not cold enough, while the freezer is cold but not freezing properly.
• The refrigerator or freezer is making unus
• ual noises, such as humming, buzzing, or rattling.
• The refrigerator or freezer is running constantly or cycling on and off frequently.
• The refrigerator or freezer has frost or ice accumulation on the walls or the evaporator coils.

If you notice any of these symptoms, you should check the freezer fan and see if it needs to be replaced.

How to replace the freezer fan on your Whirlpool refrigerator?

Before you start, make sure you unplug the refrigerator from the power source and wear gloves and safety glasses. You will also need a large flat-head screwdriver, a quarter-inch socket or nut driver, and a small flat-head screwdriver. The steps may vary slightly depending on your model, but the general procedure is as follows:

1. Remove the shelves and drawers from the freezer compartment and set them aside.
2. Remove the screws that secure the back panel of the freezer and pull it out to access the evaporator coils and the fan.
3. Disconnect the wire harness that connects the fan to the control board and remove any clips or brackets that hold the fan in place.
4. Carefully pull out the fan and blade assembly from the motor shaft and discard it.
5. Align the new fan and blade assembly with the motor shaft and push it in until it snaps into place.
6. Reconnect the wire harness and secure the fan with any clips or brackets that were removed earlier.
7. Replace the back panel of the freezer and tighten the screws.
8. Replace the shelves and drawers in the freezer compartment.
9. Plug in the refrigerator and check if the fan is working properly.

FAQs about Whirlpool refrigerator freezer fan

Q: How do I find the right part number for my Whirlpool refrigerator freezer fan?

A: You can find the model number of your refrigerator on a sticker inside the fresh food compartment or on a label behind the kickplate at the bottom front of the appliance. You can then use this model number to search for compatible parts on online stores or websites like PartsDr.com. Alternatively, you can also look for the part number on your old fan or on its packaging.

Q: How often should I replace my Whirlpool refrigerator freezer fan?

A: There is no definitive answer to this question, as it depends on several factors such as usage, maintenance, and environmental conditions. However, most experts recommend replacing your freezer fan every 5 to 10 years, or whenever it shows signs of malfunction.

Q: What are some tips to prevent freezer fan problems?

A: Some of the tips to prevent freezer fan problems are:

• Keep your refrigerator clean and dust-free, especially around the condenser coils at the back or bottom of the appliance.
• Avoid overloading your refrigerator or blocking the air vents with food items.
• Defrost your freezer regularly if it is not frost-free, or check for any leaks or gaps in the door seal that may cause frost buildup.
• Replace your water filter every 6 months or as recommended by your manufacturer.
